Aim-TTi TG2000 | DDS Function Generator | 20MHz, USB & RS232

Name: Aim-TTi TG2000 | DDS Function Generator | 20MHz, USB & RS232
Brand: Aim Tti
SKU: TG2000
Availability: OutOfStock

Part Number : TG2000

The Aim-TTi TG2000 is a 20MHz DDS function generator with digital control and USB and RS232 interfaces. It covers 0.001Hz to 20MHz with 6-digit or 1mHz resolution and produces low-distortion sine waves, making it a dependable source for education, service and general electronics development.

Key features

0.001Hz to 20MHz frequency range
6 digits or 1mHz resolution; 1ppm stability
Low distortion, high spectral purity sine waves
Internal phase-continuous lin or log sweep
AM, FSK, gated and tone switching modes
5mV to 20V pk-pk from 50 or 600 Ohms

Availability: in stock

Detailed Description
Specifications
Downloads

Aim-TTi TG1000 & TG2000 DDS Function Generators, 10MHz & 20MHz

The TG1000/2000 offers a high quality direct digital synthesis (DDS) function generator at a significantly lower price. DDS generates waveforms using a phase accumulator, look-up table and DAC. The accuracy/stability of the resulting waveform is related to that of the crystal master clock. When correctly engineered, the DDS generator offers not only exceptional accuracy and stability but also high spectral purity, low phase noise and excellent frequency agility. The TG2000 includes RS-232 and USB interfaces for remote control of all instrument functions and for remotely storing instrument set-ups.

6 digits or 1mHz setting resolution
1ppm stability and better than 10ppm absolute accuracy for one year
Sine, square, triangle, positive pulse and negative pulse waveforms
Internal sweep, linear or logarithmic, phase continuous, 0.1Hz to 20MHz
Modulations modes of sweep, gated, AM, FSK and tone switching - built-in trigger generator
5mV to 20V pk-pk output from 50Ω or 600Ω; plus multi-function auxiliary output
Storage for up to nine complete instrument set-ups in non-volatile memory

Standards

Complies with EN61010-1 and EN61326

Supplied with

Mains lead and full instructions

Part Number	TG2000
Brand	Aim-TTi
Frequency Range	0.001 Hz to 20 MHz
Resolution	6 digits or 1 mHz
Stability	1 ppm
Accuracy	10 ppm, one year
Output	5 mV to 20 V pk-pk
Output Impedance	50 or 600 Ohm
Modulation	AM, FSK, gated, tone switching
Interfaces	USB, RS232
