Aim-TTi TGR2051 | RF Signal Generator | 150kHz to 1.5GHz

Name: Aim-TTi TGR2051 | RF Signal Generator | 150kHz to 1.5GHz
Brand: Aim Tti
SKU: TGR2051
Availability: OutOfStock

Part Number : TGR2051

The Aim-TTi TGR2051 is an RF signal generator covering 150kHz to 1.5GHz with amplitude from -127dBm to +13dBm. Internal or external AM, FM and PM, fast amplitude and frequency sweeps and a colour touch screen make it suitable for receiver testing, EMC pre-work and RF teaching labs.

Key features

150kHz to 1.5GHz frequency range
-127dBm to +13dBm amplitude, 0.1dBm setting resolution
Phase noise <-117dBc/Hz typical at 1GHz, 10kHz offset
Internal or external AM, FM and PM
Fast sweeps with 5ms settling time
USB and LAN (LXI), GPIB optional; SCPI compatible

Availability: in stock

Free Kuwait shipping available

Detailed Description
Specifications
Features
Downloads

Aim-TTi Rf Signal Generator, FM Modulation, 10 Hz Resolution - TGR2051

This high-performance RF signal generator from Aim-TTi offers exceptional performance and functionality. With a wide frequency range of up to 1.5 GHz and precise frequency resolution of 10 Hz, this generator is ideal for development, test, and service work, providing accuracy, stability, and flexibility.

Features & Benefits

â€¢ Offers a maximum frequency range of 1.5 GHz
â€¢ Provides precise frequency resolution of 10 Hz
â€¢ Supports UHF frequencies up to 1000 MHz
â€¢ Features an output impedance of 50 Î© for efficient signal transmission
â€¢ Time base accuracy of Â±1 ppm ensures reliable performance
â€¢ Suitable for a wide range of applications in the automation, electronics, electrical, and mechanical industries

Applications

â€¢ Ideal for RF testing, signal analysis, and modulation applications
â€¢ Used for RF system development, calibration, and verification
â€¢ Suitable for RF signal generation in research and development labs
â€¢ Useful for RF signal modulation and frequency sweeps in production testing environments

Can it handle UHF frequencies?

Yes, the RF signal generator supports UHF frequencies up to 1000 MHz.

Will it provide accurate frequency resolution?

The generator offers precise frequency resolution of 10 Hz for detailed signal control.

Is it suitable for RF signal modulation?

Yes, it is designed for both analogue and digital modulations, making it ideal for various modulation applications.

Part Number	TGR2051
Brand	Aim-TTi
Frequency Range	150 kHz to 1.5 GHz
Amplitude	-127 dBm to +13 dBm
Amplitude Resolution	0.1 dBm
Phase Noise	<-117 dBc/Hz typ. (1 GHz, 10 kHz offset)
Frequency Accuracy	1 ppm
Analogue Modulation	AM, FM, PM
Interfaces	USB, LAN (LXI)
GPIB	Optional

150kHz to 1.5GHz frequency range
Frequency setting resolution of 10Hz at up to 1.5GHz
Amplitude range of -127dBm to +13dBm
0.1dBm amplitude setting resolution
Internal or external analogue modulations (AM, FM, PM)
Amplitude can be set in dBm, dBμV or in linear Volts
Modulation Synchronization
Fast amplitude and/or frequency sweeps with comprehensive triggering
Compatible with previous Aim-TTi RF generators
