ASCO 52100009, 5/3 W1 Pneumatic Solenoid Valve - Pilot/Pilot G 1/4 521 Series 24V dc

Name: ASCO 52100009, 5/3 W1 Pneumatic Solenoid Valve - Pilot/Pilot G 1/4 521 Series 24V dc
Brand: Asco
SKU: 52100009
Availability: OutOfStock

Part Number : 52100009

Availability: Sold out

Detailed Description
Specifications

519-520-521 series mini valves, assembly only or on manifold

3/2, 5/2 or 5/3 mini distributors for fitting onto manifolds or alone.
Stock numbers 302-6291 and 302-6308 fit onto manifolds only.
Monostable, bistable, closed centre or open centre versions.
Available in 3 different sizes: M5, G1/8" or G1/4".

Brand	Asco
Function	5/3 W1
Connection Port Thread	G 1/4
Actuation Type	Pilot/Pilot
Manufacturer Series	521
Mounting Style	Manifold
Solenoid Voltage	24V dc
Solenoid Fitted	Yes
Number of Ports	5/3
Body Material	Anodised Aluminium
Maximum Flow Rate	1050L/min
Solenoid Power Consumption	1.6W
Minimum Operating Pressure	1.5bar
Maximum Operating Temperature	+50°C
Thread Size	1/4in
Minimum Operating Temperature	+5°C
Maximum Operating Pressure	8bar
Thread Standard	G
