ASCO CYLINDERS WITH PROFILED BARREL ˜ 32 to 100 mm - double acting ISO 15552-AFNOR-DIN with pneumatic cushioning, Series 453,Type PES P-DM
Part No. Series 453 PES-P-DM
ASCO Series 453 profiled-barrel cylinders with pneumatic cushioning are double-acting ISO 15552 (AFNOR/DIN) actuators available in 32 to 100 mm bores for industrial automation. The profiled aluminium barrel supports standard ISO mounting dimensions, making the cylinder suitable for replacing compatible ISO cylinders in existing machines. Genuine ASCO cylinder, supplied in the UAE by General Tech Services LLC. Pricing is quote-based. Request a quote in under a minute - call +971 6 543 6933.
The Series 453 uses pneumatic cushioning to help control piston movement near the end of the stroke. Double-acting operation provides controlled force and movement in both directions.
The profiled barrel includes integrated grooves for position detectors such as ASCO Series 494, allowing end-of-stroke feedback devices to be mounted without additional brackets. The cylinder accepts standard ISO 15552 mountings, rod ends and guiding units.
When sizing an ASCO ISO 15552 cylinder, consider the required force, available working air pressure, stroke, friction and dynamic loads. A suitable safety margin should be included for the application. Long strokes with side loads may require an appropriate guiding unit. Share the bore, stroke, mounting and application details with our team for code and accessory confirmation.
For applications requiring adjustable cushioning, the Series 452 PLS-DM is an alternative configuration.
Ready to order the ASCO Series 453 PES-P-DM? Speak to our team. Call +971 6 543 6933
Key Benefits
-
ISO 15552 (AFNOR/DIN) dimensions for compatible drop-in replacement applications
-
32 to 100 mm bore range
-
Double-acting pneumatic operation
-
Built-in pneumatic cushioning
-
Profiled aluminium barrel
-
Integrated grooves for ASCO Series 494 position detectors
-
Compatible with standard ISO mountings, rod ends and guiding units
-
Genuine ASCO cylinder supplied in the UAE by General Tech Services LLC
Who This Product Is Best For
-
OEMs sourcing standard ISO 15552 pneumatic cylinders in the UAE
-
Maintenance teams replacing compatible ISO cylinders
-
Industrial automation and machine-building applications
-
Procurement teams sourcing cylinders in common bore sizes
-
Applications requiring end-of-stroke position detection
How to Install & Use It
-
Confirm the required bore, stroke, mounting arrangement and operating environment.
-
Select suitable ISO 15552 mountings, rod ends and guiding accessories.
-
Install compatible Series 494 position detectors in the barrel grooves if end-of-stroke feedback is required.
-
Connect the appropriate compressed-air supply and pneumatic controls.
-
Set operating speed and verify cushioning and cylinder movement under the expected load.
-
Test the complete assembly before placing the machine into normal operation.
Frequently Asked Questions
What is the ASCO Series 453 PES-P-DM cylinder?
It is a double-acting ISO 15552 (AFNOR/DIN) profiled-barrel pneumatic cylinder with pneumatic cushioning, available in 32 to 100 mm bore sizes.
Is the Series 453 interchangeable with other ISO cylinders?
The Series 453 follows ISO 15552 (AFNOR/DIN) dimensions for mounting and rod-end compatibility. Confirm the exact bore, stroke, mounting and application requirements before replacement.
Can I add position sensors to the Series 453?
Yes. The profiled barrel has integrated grooves for position detectors such as ASCO Series 494.
What bore and stroke do I need?
Bore selection depends on the required force and available working air pressure, while stroke depends on the required travel. Share the load, speed and travel requirements with General Tech Services LLC for sizing assistance.
How do I calculate the required cylinder bore?
Cylinder bore is selected according to the required force and working air pressure, with allowance for friction and dynamic loads. General Tech Services LLC can assist with the sizing calculation when you provide the application data.
Is there an alternative version with adjustable cushioning?
The ASCO Series 452 PLS-DM is an alternative cylinder configuration for applications requiring adjustable cushioning. Choose the cylinder based on the application requirements and confirm compatibility with General Tech Services LLC.
How do I choose the Series 453 or another ISO cylinder?
Choose the cylinder based on bore, stroke, mounting dimensions, operating pressure, load, speed, environment and sensor requirements. Send your application details and cylinder code to General Tech Services LLC for compatibility confirmation.
How do I get a price and lead time?
Pricing is quote-based. Call General Tech Services LLC on +971 6 543 6933 or submit the Request a Quote form.
Is this a genuine ASCO cylinder?
General Tech Services supplies original ASCO cylinders in the UAE with technical support.
