ASCO G450A6SK0025HTP | Profiled Tie Rod Cylinders | Port Type G3/8 | Series G450
ASCO G450A6SK0025HTP | Profiled Tie Rod Cylinder, G3/8", 63 mm Bore x 25 mm Stroke
The ASCO G450A6SK0025HTP is a Series G450 profiled tie rod pneumatic cylinder built to the ISO 15552 standard, featuring a 63 mm bore, 25 mm stroke, and G3/8" port connection. It has an aluminium body and is rated for 10 bar operating pressure, with an ambient temperature range of -20°C to +70°C.
The cylinder incorporates self-lubricating bearings, non-abrasive scraper seals, a hard chrome-plated steel rod, and hard anodized aluminium tie rods for industrial pneumatic applications. Genuine ASCO stock is available from General Tech Services LLC, Kuwait, with Kuwait-wide delivery.
For pricing and current stock availability, call +965 9807 4888.
Part Number: G450A6SK0025HTP
Product Description
The ASCO G450A6SK0025HTP is a Series G450 profiled tie rod pneumatic cylinder designed according to the ISO 15552 standard for industrial automation and pneumatic applications. It features a 63 mm bore and 25 mm stroke, providing a compact linear actuation solution for compatible machinery.
The cylinder has a G3/8" port connection and an aluminium body. It is rated for a maximum operating pressure of 10 bar and is specified for an ambient temperature range of -20°C to +70°C.
The G450 series incorporates self-lubricating bearings and non-abrasive scraper seals. The piston rod is manufactured from hard chrome-plated steel, while the tie rods use hard anodized aluminium.
For operation, filtered or unfiltered inert gas or air is recommended as the operating medium, according to the supplied product information.
Key Benefits
- ISO 15552 profiled tie rod pneumatic cylinder
- 63 mm bore × 25 mm stroke
- G3/8" port connection
- Aluminium cylinder body
- Self-lubricating bearings
- Non-abrasive scraper seals
- Hard chrome-plated steel piston rod
- Hard anodized aluminium tie rods
- Maximum operating pressure of 10 bar
- Ambient temperature range of -20°C to +70°C
- Suitable for filtered or unfiltered inert gas or air
- Genuine ASCO stock available in Kuwait
- Specified weight of 1.63 kg
Who This Product Is Best For
- OEMs and system integrators specifying an ISO 15552 profiled tie rod cylinder
- Automation engineers requiring a 63 mm bore and 25 mm stroke
- Pneumatic systems using G3/8" port connections
- Maintenance teams replacing a compatible Series G450 cylinder
- Industrial automation applications requiring compact pneumatic linear actuation
How to Specify & Install It
- Confirm bore and stroke: Verify that the 63 mm bore and 25 mm stroke meet the application's required movement and force requirements.
- Check port compatibility: Confirm that the G3/8" port connection is compatible with the existing pneumatic lines and fittings.
- Verify pressure requirements: Ensure the application's operating pressure remains within the specified 10 bar rating.
- Check environmental conditions: Confirm that the ambient operating temperature remains within the specified -20°C to +70°C range.
- Mount the cylinder: Securely mount the cylinder and ensure correct alignment with the moving load to avoid unnecessary side loading.
- Connect the air supply: Use filtered or unfiltered inert gas or air as specified for the application.
- Test before commissioning: Check cylinder movement, connections, alignment and leakage before placing the system into operation.
Frequently Asked Questions
What is the ASCO G450A6SK0025HTP cylinder used for?
It is an ISO 15552 profiled tie rod pneumatic cylinder designed for industrial automation and pneumatic applications.
What are the bore and stroke dimensions?
The cylinder has a 63 mm bore and 25 mm stroke.
What port connection does it use?
It uses a G3/8" port connection.
What is the maximum operating pressure?
The cylinder is rated for a maximum operating pressure of 10 bar.
What is the operating temperature range?
The specified ambient temperature range is -20°C to +70°C.
What is the cylinder body made from?
The cylinder has an aluminium body.
What material is used for the piston rod?
The piston rod uses hard chrome-plated steel.
What type of bearings and seals does it use?
The cylinder features self-lubricating bearings and non-abrasive scraper seals.
What operating medium is recommended?
Filtered or unfiltered inert gas or air is recommended according to the supplied product information.
What is the weight of the cylinder?
The specified weight is 1.63 kg.
Is genuine ASCO stock available in Kuwait?
Yes. Genuine ASCO G450A6SK0025HTP stock is available from General Tech Services LLC, Kuwait.
How can I check pricing and current availability?
For pricing and current stock availability, call +965 9807 4888.
