ASCO G653AR005GA00N0, G 3/4 Pneumatic Regulator - 0.5bar to 16bar, G 3/4 in, 20bar max. input,
Genuine ASCO (Emerson) parts from General Tech Services LLC, UAE, with free UAE-wide shipping available.
Part No. G653AR005GA00N0
Product Overview
The ASCO G653AR005GA00N0 is a Series 653 pneumatic pressure regulator designed to reduce compressed-air supply pressure to a stable, adjustable outlet pressure. It helps downstream pneumatic equipment operate at the pressure required for the application rather than continuously using the full available line pressure.
A pneumatic regulator can help maintain a controlled outlet pressure when supply pressure or downstream demand changes. This makes it useful for pneumatic machinery where consistent operating pressure is important for cylinder force, actuator performance, pneumatic tools and other air-operated equipment.
The G653AR005GA00N0 is listed with G 3/4 connections, an adjustable set pressure range of 0.5–16 bar and a maximum input pressure of 20 bar. It belongs to the ASCO Series 653 air-preparation range from Emerson.
Typical applications include pneumatic clamping and pressing stations, packaging machinery, assembly equipment, pneumatic tools and industrial air circuits where controlled downstream pressure is required. Operating equipment at an appropriate pressure can also help reduce unnecessary compressed-air consumption and limit excessive loading of pneumatic components.
Before ordering, confirm the required connection size, pressure range, maximum inlet pressure and application flow requirements. A pressure gauge can be used to monitor the regulated outlet pressure during setup and operation.
For replacement applications, check the complete part number on the existing regulator before ordering to ensure the correct ASCO variant is selected.
Key Benefits
- Provides adjustable downstream air-pressure control
- G 3/4 pneumatic connections, as listed
- Adjustable set pressure range of 0.5–16 bar
- Maximum input pressure of 20 bar
- Helps maintain controlled outlet pressure
- Suitable for ASCO Series 653 air-preparation applications
- Supports controlled pressure for cylinders, tools and pneumatic equipment
- Full part-number identification supports replacement sourcing
- Genuine ASCO (Emerson) supply through General Tech Services LLC
- Free UAE-wide shipping available
For current pricing and lead time, call +971 6 543 6933.
Who This Product Is Best For
- Maintenance teams replacing an existing ASCO pneumatic regulator
- Machine builders requiring adjustable compressed-air pressure
- Packaging and assembly equipment manufacturers
- Engineers working with pneumatic cylinders, tools and actuators
- Industrial facilities requiring controlled downstream pressure
- Procurement teams sourcing exact ASCO Series 653 part numbers
How to Install & Use It
- Confirm that the G 3/4 connection, 0.5–16 bar set range and 20 bar maximum inlet pressure are suitable for the pneumatic circuit.
- Isolate the compressed-air supply and fully depressurize the system before installation.
- Install the regulator in the pneumatic line according to the manufacturer's flow-direction requirements.
- Connect a suitable pressure gauge where required to monitor the regulated outlet pressure.
- Restore the air supply gradually and check all connections for leakage.
- Adjust the regulator until the downstream pressure reaches the required operating value.
- Test the connected pneumatic equipment under normal operating conditions.
Installation and commissioning should be performed by qualified personnel familiar with compressed-air systems and the manufacturer's requirements.
Frequently Asked Questions
What does the ASCO G653AR005GA00N0 pneumatic regulator do?
It reduces incoming compressed-air pressure to an adjustable downstream pressure, helping pneumatic equipment operate at a controlled pressure.
What port size does the G653AR005GA00N0 have?
The listed connection size is G 3/4.
What pressure range can it be set to?
The listed adjustable set pressure range is 0.5–16 bar.
What is the maximum inlet pressure?
The listed maximum input pressure is 20 bar.
What series does the G653AR005GA00N0 belong to?
It is an ASCO Series 653 pneumatic pressure regulator.
What is the difference between G653AR005GA00N0 and G653AR005GA00H0?
The supplied product information identifies both as G 3/4 Series 653 regulator variants, but the G653AR005GA00N0 is listed with a 0.5–16 bar set range, while the G653AR005GA00H0 is listed with a 0.5–10 bar set range. The required pressure range should therefore be checked before ordering.
Can this regulator be used for pneumatic cylinders?
It can be used in pneumatic systems where controlled air pressure is required for connected equipment such as cylinders and actuators, provided the regulator's pressure, connection and flow requirements are suitable for the application.
Is genuine ASCO stock available in the UAE?
General Tech Services LLC supplies genuine ASCO (Emerson) parts to industrial customers across the UAE, with free UAE-wide shipping available.
What details should I provide when requesting a quote?
Provide the complete part number, required quantity and delivery location. Application pressure and flow requirements can also help confirm the appropriate ASCO variant.
How much does the ASCO G653AR005GA00N0 cost?
Pricing is quote-based. Call +971 6 543 6933 for current pricing and lead time.
Request a Quote Today
For pricing, availability or ordering assistance, contact General Tech Services LLC, UAE.
Call +971 6 543 6933 for current pricing and lead time.
