ASCO R880G02FGM | Precision Regulator | High Flow | Series R88 | Port Connection G1/4
ASCO R880G02FGM | R88 Series Precision Regulator
Genuine ASCO R880G02FGM precision regulator, in stock at General Tech Services LLC, Kuwait. Designed for the R80/R82/R88 multi-stage regulator range, this high-flow precision regulator provides stable pressure control through a G1/4" port connection and is built for continuous industrial pneumatic service.
Call +965 9807 4888 for pricing and stock availability.
Part No. R880G02FGM | R88 Series Precision Regulator
Product Description
The ASCO R880G02FGM is a precision regulator from the R88 series, designed for industrial pneumatic systems requiring stable and accurate pressure control. Its die-cast zinc body and NBR diaphragms provide a durable construction for continuous-duty applications.
A continuous-bleed pilot diaphragm design enables smooth valve movement across the regulator's operating range. The unit provides a flow coefficient of 6.7 m³/h through its G1/4" port connection and supports a pressure range of 2 to 150 PSI, with a maximum working pressure of 10 bar.
The regulator is suitable for installations operating across a wide ambient temperature range of -40°C to +71°C.
Key Benefits
- High-flow precision regulation with a flow coefficient of 6.7 m³/h
- Continuous-bleed pilot diaphragm design for smooth valve movement
- Die-cast zinc body with NBR diaphragms for long service life
- G1/4" port connection for straightforward pneumatic system integration
- Pressure range of 2 to 150 PSI
- Maximum working pressure of 10 bar
- Ambient temperature range of -40°C to +71°C
- Genuine ASCO part with local Kuwait stock availability
Who This Product Is Best For
- Process engineers requiring stable pressure regulation on a G1/4" pneumatic line
- Plants replacing an existing R80/R82/R88 series precision regulator
- Industrial facilities requiring high-flow pressure control
- Pneumatic systems operating across a wide ambient temperature range
How to Specify & Install It
- Confirm that the required pressure range and G1/4" port size match your pneumatic application.
- Install the regulator in the correct flow direction on the compressed air line.
- Adjust the outlet pressure within the specified 2 to 150 PSI range.
- Pressurize the system gradually and verify stable, accurate pressure control before full commissioning.
Frequently Asked Questions
What is the ASCO R880G02FGM regulator used for?
It is a precision pneumatic regulator designed to provide stable and accurate pressure control in industrial systems.
What is the flow coefficient of the R880G02FGM?
The regulator has a flow coefficient of 6.7 m³/h.
What is the port size?
The regulator has a G1/4" port connection.
What is the body material?
The body is made from die-cast zinc and uses NBR diaphragms.
What is the pressure range?
The specified pressure range is 2 to 150 PSI, with a maximum working pressure of 10 bar.
What ambient temperature range is supported?
The specified ambient temperature range is -40°C to +71°C.
Is genuine ASCO R880G02FGM stock available in Kuwait?
Yes. Genuine ASCO R880G02FGM stock is available through General Tech Services LLC, Kuwait. Call +965 9807 4888 for current pricing and availability.
For pricing and current stock availability, call +965 9807 4888.
