AVENTICS 0822332512 Roundline Cylinder - , 16mm Bore, 500mm Stroke, MNI Series, Double Acting

Name: AVENTICS 0822332512 Roundline Cylinder - , 16mm Bore, 500mm Stroke, MNI Series, Double Acting
Brand: Aventics
SKU: 0822332512
Availability: OutOfStock

Part Number : 0822332512

Availability: Sold out

Detailed Description
Specifications

The Aventics formidable mini cylinder, crafted meticulously as part of the MNI Series, stands out for its exceptional design, offering robust performance tailored for general machine construction. With its ISO 6432 compliance, this cylinder ensures reliability and longevity, making it a prime choice for various industrial applications. It boasts a double-acting mechanism for enhanced efficiency, coupled with pneumatic adjustable cushioning that delivers smooth operation, significantly reducing wear and tear. The stainless steel piston rod and brass piston construction combine durability with superior functionality, while its impressive range of environmental certifications ensures that it meets the stringent demands of contemporary industry requirements. From its compact form factor to its effective performance under varying conditions, this product exemplifies precision engineering and utility.

Engineered for general machine construction with a sturdy build
Double-acting functionality enhances operational efficiency
Pneumatic adjustable cushioning provides smooth, controlled movement
Constructed with stainless steel and brass for exceptional durability
ISO 6432 compliance ensures compatibility and reliability
Operates effectively at a range of working pressures from 1 to 10 bar
Meets diverse environmental requirements, including optional ATEX certification
Lightweight design simplifies installation and operation

Brand	AVENTICS
Manufacturer Series	MNI
Model Number p	0822332512
Action	Double
Stroke	500mm
Bore	16mm
Port Connection	M5
Pneumatic Connection	M5
Piston Rod Thread Gender	Male
Cushioning Type	Pneumatic Cushioning
Maximum Operating Pressure	10 bar
ISO Standard	ISO 6432
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	+80°C
