CONCOA 8066530-01-1 | 6530 Series Liquid Cylinder Regulator | Oxygen, CGA 540, 200 PSIG Delivery
Part Number : 8066530-01-1
CONCOA 8066530-01-1 is the oxygen liquid cylinder regulator of the 6530 Series Liquid Cylinder Regulator line, with a CGA 540 inlet and a 9/16 in -18 (B) RH Ext outlet. Delivery pressure is adjustable up to 200 PSIG (14 BAR) and the outlet gauge reads 0-400 PSIG/0-2800 kPa.
Key features
- Suitability for gas withdrawal from cryogenic liquid cylinders, plus a 316L stainless steel diaphragm for cold liquid cylinder use
- A self-seating relief valve against liquid flash and an internal filter protecting the PTFE seat
- A 3000 PSIG (210 BAR) maximum inlet pressure with a chrome-plated forged brass body
- A chrome-plated, die-cast zinc bonnet, plus a 2 1/2 in (63 mm) gauge with plated case
For pricing, please contact our experts.
