CONCOA 8066531-01-1 | 6530 Series Liquid Cylinder Regulator | Carbon Dioxide, CGA 320, 120 PSIG Delivery
Part Number : 8066531-01-1
Part 8066531-01-1 configures the 6530 Series Liquid Cylinder Regulator for carbon dioxide, combining a CGA 320 inlet with a 5/8 in -18 (B) RH Int outlet. It regulates up to 120 PSIG (8 BAR), shown on a 0-200 PSIG/0-1400 kPa outlet gauge.
Key features
- Suitability for gas withdrawal from cryogenic liquid cylinders with a CAPSULE® seat assembly for serviceability
- A 316L stainless steel diaphragm for cold liquid cylinder use, plus a self-seating relief valve against liquid flash
- An internal filter protecting the PTFE seat and a 3000 PSIG (210 BAR) maximum inlet pressure
- A chrome-plated forged brass body with a chrome-plated, die-cast zinc bonnet
For pricing, please contact our experts.
