Dakota F-000-7105 | Acrylic Delay Line Tip | 1/2 x 5/8 in

Name: Dakota F-000-7105 | Acrylic Delay Line Tip | 1/2 x 5/8 in
Brand: Dakota Ultrasonics
SKU: F-000-7105
Availability: OutOfStock

Part Number : F-000-7105

Dakota F-000-7105 is an acrylic delay line tip sized 1/2 x 5/8 in. The tip sits on a single element probe and delays the sound pulse so that thin parts can be gauged accurately. Acrylic tips like this one suit steel, aluminium and titanium with the gauge set to interface-echo or echo-echo mode.

Key features

Size: 1/2 x 5/8 in
Material: Acrylic
Type: Delay Line Tip

Availability: in stock

Specifications

Part Number	F-000-7105
Brand	Dakota Ultrasonics
Size	1/2 x 5/8 in
Type	Delay Line Tip
Material	Acrylic
