DeFelsko PRBDPMS | PosiTector DPM S Probe Only | Magnetic Surface Sensor, Gage Body Required
The DeFelsko PRBDPMS is the PosiTector DPM S probe (integral probe with cabled magnetic surface temperature sensor) sold without a gage body. Connected to a PosiTector Standard or Advanced body, it measures relative humidity, air temperature, surface temperature, dew point and surface-minus-dew-point. It lets existing PosiTector owners add climate checks on steel structures to their inspection kit.
Key features
- Probe only – a PosiTector gage body is required
- Measures relative humidity, air temperature, surface temperature, dew point and surface-minus-dew-point
- Magnetic surface temperature sensor with armoured cable
- Locking device on the cable and a magnetic tab for mounting the body on steel
- Also accepts other optional K-type thermocouple sensors
- Wet bulb temperature shown on Advanced (3) bodies only
- Specifications
- Downloads
| Part Number | PRBDPMS |
| Brand | DeFelsko |
| Probe Model | PosiTector DPM S |
| Probe Style | Integral probe with cabled magnetic surface temperature sensor |
| Supply | Probe only (gage body required) |
| Measured Parameters | Relative humidity, air temperature, surface temperature, dew point and surface-minus-dew-point |
| Air Temperature | -40 to 80 °C, ±0.5 °C |
| Relative Humidity | 0–100%, ±3% |
| Dew Point | -60 to 80 °C, ±3 °C (RH dependent) |
| Standards | ISO 8502-4, BS 7079-B4, ASTM D3276, IMO PSPC, SSPC-PA7, US Navy NSI 009-32 |
