DMQ QC5 DLC | Advanced Dry Coating Thickness Gauge for Ferrous and Non Ferrous with Datalogger | Range 0 to 15mm / 0 to 5.905in
Demeq's QC5 DLC is the most comprehensive and advanced dry coating thickness gauge on the market. It has 9 calibration modes, calibration memory, a continuous measurement mode, and much more. It uses a combination Ferrous/Non-Ferrous probe to automatically recognise the type of substrate.
With the QC5 DLC, you can also use the DMQ DataCenter programme to transport data from the unit memory to a PC.
- Specifications
- Features
- Downloads
| Alarm | Low & High, user defined Alarm types Visible: Flashing backlight and irregular digits Audible: Intermitent beep |
| Connection | USB to connect to a PC or RS232 (optional cable) Type Lemo "0B" connector for probe |
| Measurement method | Ferrous / Non-Ferrous Base Eddy Current - Magnetic Induction Range: 0 - 1500µm 0 - 60Mils Resolution: 1µm 0.1Mil |
| Power Supply | 2 x AA 1.5v Alkaline 2 x AA 1.2v Ni-MH Rechargeable Easy slide battery compartment cover |
- Type of base indicator
- Coupling indicator
- Continuos measurement mode
- Differential mode
- Count layers (number of layers in a coating)
- Graphics
- Statistics
