Dwyer 1222-20-D | Flex-Tube U-Tube Manometer | 10-0-10" w.c.
Scaled 10-0-10 in w.c., the Dwyer 1222-20-D belongs to the Series 1222 Flex-Tube U-tube range and reads positive, negative or differential pressure.
- 10-0-10 in w.c. range on the 1222-20-D
- The 1222-20-D combines a plain U-tube with durable plastic construction
- Shatter-proof 0.375 in O.D. butyrate tubing forms the 1222-20-D columns
- Cleaning the 1222-20-D is simple as the columns are accessible
- 1222-20-D scale is extruded high-impact polystyrene to hold column alignment
- High-contrast 1222-20-D scale: black graduations silkscreened on white
- Specifications
- Features
- Downloads
| Part Number | 1222-20-D |
| Brand | Dwyer |
| Series | 1222 Flex-Tube |
| Type | U-tube manometer |
| Range | 10-0-10" w.c. |
| Tubing | 0.375" O.D. butyrate |
| Scale Material | High-impact polystyrene |
- All the characteristics of the 1221 are included, along with a clamp bar to prevent U-tube slippage and magnetic clips for installation to any vertical steel surface.
- Particularly advised for manometers that use mercury.
- The user can simply remove and replace both magnets whenever it's convenient for them.
- Static pressure in ducts.
- Laboratories for calibration.
- Monitoring of filters.
