Dwyer 165EL | PRECISOR II Positioner | 4-20 mA input, 0.5-6" stroke
Part Number : 165EL
Dwyer 165EL is a PRECISOR II electro-pneumatic positioner that takes a 4-20 mA DC input and positions linear valves across a 0.5 to 6" (10 to 150 mm) stroke. Switching between direct and reverse action is straightforward, and low air use helps keep running costs down.
- 165EL accuracy figures: linearity ±0.2% FS, repeatability ±0.5% FS, hysteresis 1% FS
- 165EL air supply 20-100 psig (1.4-6.9 bar), consumption 0.10 scfm at 20 psig
- Flow capacity of the 165EL: 28 scfm (80 LPM) at 20 psig supply
- 165EL enclosure rated IP66 (NEMA 4X)
- 165EL ports: 1/4" NPT air supply, 1/8" NPT gauge, 1/2" NPT conduit
Free Kuwait shipping available
For pricing, please contact our experts.
