Dwyer Instruments 3MSV-SD340 | Compact 3-way ball valve | 316SS | 3/8" tube | 6.35 mm orifice
The Dwyer 3MSV-SD340 is a compact 316 stainless steel 3-way ball valve with a 3/8" tube fitting connection and 6.35 mm orifice. Designed for directional and diverting flow control in instrumentation and small industrial systems, it combines a microfinished ball, PTFE seats, and a straight-through flow design for reliable operation and low pressure drop.
Request a quote in under a minute — call +971 6 5436933.
Part Number: 3MSV-SD340
The Dwyer 3MSV-SD340 is a compact 3-way ball valve engineered for directional flow control in instrumentation and small industrial systems. Its 316 stainless steel body provides a durable construction for demanding instrumentation applications, while the 3/8" tube fitting connection allows direct installation into compatible tubing systems and process lines.
The valve features a 6.35 mm orifice and a microfinished ball with PTFE seats, providing a reliable, low-torque seal. Its straight-through flow design helps minimize pressure drop while supporting efficient fluid routing.
With a maximum pressure rating of 1500 psig (103 bar) and an operating temperature range of -40° to 350°F, the 3MSV-SD340 is suitable for instrumentation applications where flow needs to be directed or diverted between ports rather than simply turned on or off.
For applications requiring a brass body, the Dwyer 3MSV-BD340 provides the same 3/8" tube fitting connection, 6.35 mm orifice, and 3-way configuration with a brass body.
Ready to order the 3MSV-SD340? Speak to our team. Call +971 6 5436933.
Key Benefits
- Compact 3-way design for directional and diverting flow control
- 3/8" tube fitting connection
- 6.35 mm orifice
- 316 stainless steel body
- Microfinished ball and PTFE seats for reliable, low-torque operation
- Straight-through flow design helps minimize pressure drop
- Maximum pressure rating of 1500 psig (103 bar)
- Operating temperature range of -40° to 350°F
- Suitable for instrumentation and small industrial flow-control systems
Who This Product Is Best For
The Dwyer 3MSV-SD340 is suited for instrumentation and controls technicians, process engineers, and system integrators who need a compact 3-way stainless steel ball valve for directing or diverting fluid flow.
Its 3/8" tube fitting connection makes it suitable for panel-mounted instrumentation and small process systems where compact installation and reliable flow control are required.
How to Use
- Install the 3MSV-SD340 at the required directional or diverting flow point using its 3/8" tube fitting connection.
- Verify that the three-port orientation corresponds with the intended flow path before commissioning.
- Check all tubing connections for proper installation and sealing.
- Cycle the valve through its positions to confirm smooth operation.
- Place the system into service after confirming the valve operates correctly within the application's pressure and temperature limits.
Frequently Asked Questions
What does the Dwyer 3MSV-SD340 do?
The 3MSV-SD340 is a 3-way ball valve designed to direct or divert fluid flow between its ports rather than simply opening or closing a single flow path.
What material is the 3MSV-SD340 body?
The valve body is made from 316 stainless steel.
What connection does the 3MSV-SD340 use?
It uses a 3/8" tube fitting connection.
What is the orifice size?
The Dwyer 3MSV-SD340 has a 6.35 mm orifice.
What is the maximum pressure rating?
The maximum pressure rating is 1500 psig (103 bar).
What is the operating temperature range?
The specified temperature range is -40° to 350°F.
What is the difference between the 3MSV-SD340 and 3MSV-BD340?
Both are compact 3-way ball valves with a 3/8" tube fitting connection and 6.35 mm orifice. The 3MSV-SD340 has a 316 stainless steel body, while the 3MSV-BD340 has a brass body.
Does GeneralTech Shop deliver the 3MSV-SD340 across the UAE?
For UAE availability and delivery timelines, contact GeneralTech Shop at +971 6 5436933.
