Dwyer Instruments DTFF-1S-10W | Variable-Area Flowmeter for Low Flow Rates | Range 0-10 GPH | Water calibration | 1/4" NPT - generaltechuae

Dwyer DTFF-1S-10W | Fixed-Orifice Low-Flow Meter | 0-10 GPH water, 1/4" female NPT

Part Number : DTFF-1S-10W

The Dwyer DTFF-1S-10W is a fixed-orifice flowmeter calibrated for water, reading 0-10 GPH through a 1/4" female NPT connection. The DTFF-1S-10W is rated to 3000 psig (200 bar) with a 316 stainless steel body and is calibrated for installation in a horizontal line.

  • DTFF-1S-10W accuracy: ±2% FS; repeatability ±1% FS
  • 0-10 GPH water scale on a 63.5 mm (2.5") dial (DTFF-1S-10W)
  • DTFF-1S-10W wetted parts: 302 SS spring and range spring, PTFE-coated magnet, acetal orifice piston, fluoroelastomer diaphragm
  • DTFF-1S-10W weighs 4 lb (1.81 kg)
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
