Dwyer DTFF-1S-40W | Fixed-Orifice Low-Flow Meter | 0-40 GPH water, 1/4" female NPT

Part Number : DTFF-1S-40W

The Dwyer DTFF-1S-40W is a fixed-orifice flowmeter calibrated for water, reading 0-40 GPH through a 1/4" female NPT connection. The DTFF-1S-40W is rated to 3000 psig (200 bar) with a 316 stainless steel body and is calibrated for installation in a horizontal line.

  • Accuracy of the DTFF-1S-40W is ±2% FS, with ±1% FS repeatability
  • Range 0-40 GPH water shown on a 2.5" (63.5 mm) dial face (DTFF-1S-40W)
  • DTFF-1S-40W wetted parts: 302 SS spring and range spring, PTFE-coated magnet, acetal orifice piston, fluoroelastomer diaphragm
  • DTFF-1S-40W weighs 4 lb (1.81 kg)
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
