Dwyer IP-44 | Current to Pressure Transducer | 6-30 psi (40-200 kPa), Electrical: 1/2" female NPT
Part Number : IP-44
The Dwyer IP-44 is a current to pressure transducer with output 6-30 psi (40-200 kPa), connection Electrical: 1/2" female NPT and air consumption 0.03 SCFM (0.5 m³/h) typical. Dwyer lists loudness booster integrated in., minimal use of air. and adaptable zero plus span settings. among its features.
- Air Consumption: 0.03 SCFM (0.5 m³/h) typical
- Air Pressure: Minimum: 3 psig (21 kPa) above maximum output; Maximum: 100 psig (700 kPa)
- Approvals: CE, FM
- Connection: Electrical: 1/2" female NPT
- Connection: Pressure: 1/4" female NPT
- Hysteresis: <1% of span
- Input Impedance: 220 ohms
- Input Signal: 4-20 mA
