Dwyer LPTK-03 | Gas Pressure Test Kit | 0-4 kPa and 0-40 mbar
The Dwyer LPTK-03 is a low pressure gas test kit with a dual-range gauge reading 0-4 kPa and 0-40 mbar. A calibration screw on the back of the 0-40 mbar gauge keeps both ranges within 3% of full scale.
- Gauge housed in black steel
- Works from -40 to 65°C
- ±3% full-scale accuracy per range
- 63 mm gauge, recalibrated via a screw on the back
- 1/8" NPT brass hose barb and 36" rubber hose
- Specifications
- Features
- Downloads
| Part Number | LPTK-03 |
| Brand | Dwyer |
| Ranges | 0-4 kPa; 0-40 mbar |
| Accuracy | ±3% full scale |
| Gauge Size | 2-1/2" (63 mm) |
| Process Connection | 1/8" NPT, brass hose barb |
| Hose | Rubber, 36" (91.4 cm) |
| Wetted Materials | Gauge: brass; hose: rubber |
| Gauge Housing | Steel, black finish |
| Case | ABS plastic |
| Max. Pressure | 110% of range |
| Temperature Limits | -40 to 150°F (-40 to 65°C) |
| Weight | 1.75 lb (0.8 kg) |
- A calibration screw located on the gage's rear.
- Easy-to-use interface that is straightforward.
