Dwyer LPTK-04 | Gas Pressure Test Kit | 0-8 kPa and 0-80 mbar
The Dwyer LPTK-04 is a low pressure gas test kit with a dual-range gauge reading 0-8 kPa and 0-80 mbar. Both the 0-8 kPa and 0-80 mbar ranges hold ±3% full-scale accuracy, and the kit ships in a protective case.
- Operating temperature -40 to 150°F
- Both scales within ±3% of full scale
- 2-1/2" gauge with easy rear calibration
- Brass 1/8" NPT barb with a 91.4 cm rubber hose
- Stored in a protective ABS case
- Specifications
- Features
- Downloads
| Part Number | LPTK-04 |
| Brand | Dwyer |
| Ranges | 0-8 kPa; 0-80 mbar |
| Accuracy | ±3% full scale |
| Gauge Size | 2-1/2" (63 mm) |
| Process Connection | 1/8" NPT, brass hose barb |
| Hose | Rubber, 36" (91.4 cm) |
| Wetted Materials | Gauge: brass; hose: rubber |
| Gauge Housing | Steel, black finish |
| Case | ABS plastic |
| Max. Pressure | 110% of range |
| Temperature Limits | -40 to 150°F (-40 to 65°C) |
| Weight | 1.75 lb (0.8 kg) |
- A calibration screw located on the gage's rear.
- Easy-to-use interface that is straightforward.
