Dwyer MC2016 | Multi-Cal Pressure Module | 100 psig Gage Pressure
Dwyer MC2016 brings 100 psig gage pressure capability to the Multi-Cal portable calibrator, with ±0.05 listed accuracy and NIST calibration certification supplied.
- 100 psig gage pressure range; overpressure 2x range
- Two modules can be fitted to the calibrator together
- Comes with NIST calibration certification
- Reads in in H2O, psi, in Hg, kPa, mbar, cm H2O, mm Hg or custom units
- Process port: 1/8" female NPT
- Calibrator has a 9-pin RS232 serial interface
- Specifications
- Features
- Downloads
| Part Number | MC2016 |
| Brand | Dwyer |
| Range | 100 psig gage |
| Accuracy | ±0.05 |
| Overpressure | 2x range |
| Process Connection | 1/8" female NPT |
| Measuring Units | in H2O, psi, in Hg, kPa, mbar, cm H2O, mm Hg, user-defined |
| Output | RS232 serial, 9-pin |
| Calibration | NIST certification included |
| Module Weight | 0.5 lb (0.3 kg) |
| Storage Temperature | -4 to 158°F (-20 to 70°C) |
- Monitoring of Clean Room Control Filter Performance.
- Testing and Configuration of HVAC Draft Measurement.
- Laminar flowhoods with airflow measurement control and differential pressure measurement.
- Industrial Ovens, Paint Booths, and Fume Hoods.
- Utilize as a Backup Standard for Pressure Equipment Calibration.
