Dwyer PV13 | Solenoid Pilot Valve | 24 VAC, for 1-3/4" SAV Actuator
Part Number : PV13
Mounting directly onto 1-3/4" Series SAV angle seat valve actuators, the Dwyer PV13 is a 24 VAC three-way normally closed solenoid pilot valve. An electrical signal to the PV13 shifts the actuator from closed to open, or the reverse for normally open valves, and the valve returns to its normal position once the signal stops.
- Actuator port 1/8" BSP and 1/8" NPT pilot media port on the PV13
- PV13 pilot media: air, water or inert gases (water needs a drain line on the exhaust)
- IP65 with the supplied DIN connector; manual override on the PV13
- Niploy-coated brass body with FKM seal; the PV13 mounts by banjo connection
- PV13 ratings: 150 psig (10.3 bar), -10 to 60°C
