Dwyer PV14 | Solenoid Pilot Valve | 24 VDC, for 1-3/4" SAV Actuator
Part Number : PV14
Dwyer's PV14 pilots 1-3/4" Series SAV angle seat valve actuators from a 24 VDC signal. This three-way, normally closed electro-pneumatic valve moves the actuator when energised and blocks the pneumatic supply again when de-energised, letting the PV14 return the valve to its usual state.
- PV14 pilot media: air, water or inert gases (water needs a drain line on the exhaust)
- IP65 with the supplied DIN connector; manual override on the PV14
- Niploy-coated brass body with FKM seal; the PV14 mounts by banjo connection
- PV14 ratings: 150 psig (10.3 bar), -10 to 60°C
- PV14 coil voltage: 24 VDC
Free Kuwait shipping available
For pricing, please contact our experts.
