Dwyer PV24 | Solenoid Pilot Valve | 24 VDC, for 2-1/2" SAV Actuator
Part Number : PV24
The Dwyer PV24 is a three-way, normally closed electro-pneumatic solenoid pilot valve powered at 24 VDC and sized for 2-1/2" diameter Series SAV angle seat valve actuators, onto which it mounts directly. When the PV24 coil is energised it drives the actuator open (or closed on normally open valves); removing the signal blocks the supply pressure again.
- PV24 coil voltage: 24 VDC
- Actuator port 1/4" BSP and 1/8" NPT pilot media port on the PV24
- PV24 pilot media: air, water or inert gases (water needs a drain line on the exhaust)
- IP65 with the supplied DIN connector; manual override on the PV24
- Niploy-coated brass body with FKM seal; the PV24 mounts by banjo connection
Free Kuwait shipping available
For pricing, please contact our experts.
