Dwyer RDCS25T | Springless Dust Collector Valve | 1", NPT, Remote Coil

Name: Dwyer RDCS25T | Springless Dust Collector Valve | 1", NPT, Remote Coil
Brand: Dwyer
SKU: RDCS25T
Availability: OutOfStock

Part Number : RDCS25T

Dwyer's RDCS25T (1", NPT threaded connection, remote coil) is a springless pulse diaphragm valve for the cleaning air pulse in dust collectors run by Series DCT1000 or DCT500 timer boards.

1" valve, NPT threaded connection (RDCS25T)
Remote coil (RDCS25T)
Aluminium body, TPU diaphragm disc, NBR solenoid seals (RDCS25T)
Pressure range of the RDCS25T: 4.4 to 124.7 psi (0.3 to 8.6 bar)
RDCS25T: media -20 to 85 °C, ambient -20 to 60 °C, CE

Availability: in stock

Free Kuwait shipping available

Specifications
Features
Downloads

Part Number	RDCS25T
Brand	Dwyer
Type	Springless Dust Collector Valve
Valve Size	1"
Process Connection	NPT
Solenoid	Remote coil
Wetted Materials	Aluminium body, TPU diaphragm disc, NBR solenoid seals
Operating Pressure	0.3 to 8.6 bar (4.4 to 124.7 psi)
Media Temperature	-20 to 85 °C (-4 to 185 °F)
Ambient Temperature	-20 to 60 °C
Approvals	CE

Diaphragm made of thermoplastic polyurethane for extended life.
High flow rate to provide thorough cleaning.
The spring-free diaphragm design removes it.
The valve can be installed in any orientation.
Quick response time both on and off.
