Dwyer RHP-2D2D | Duct Mount RH/Temperature Transmitter | 2% RH, 0-10 VDC RH, 100 Ohm RTD Curve D Output
Dwyer RHP-2D2D: a 2% accuracy-class duct mount RH/temperature transmitter giving 0-10 VDC for RH and a 100 Ohm RTD Curve D temperature output. This 0-10 VDC, 100 Ohm RTD Curve D version is powered from 15-35 VDC or 15-29 VAC and uses a capacitance polymer sensing element with a 15 second response.
- Duct models offer an optional alphanumeric LCD; compensated from -4 to 140°F (-20 to 60°C)
- Screw terminal block that unplugs for wiring; CE approved
- RH transmitted as 0-10 VDC
- Passive temperature element: 100 Ohm RTD Curve D
- Power 15-35 VDC or 15-29 VAC
- Specifications
- Features
- Downloads
| Part Number | RHP-2D2D |
| Brand | Dwyer |
| Power | 15-35 VDC or 15-29 VAC |
| Response Time | 15 s |
| Drift | <1% RH/year |
| Mounting | Duct |
| Temperature Output | 100 Ohm RTD Curve D (passive) |
| Enclosure Rating | NEMA 4X (IP66), housing |
| Output | 0-10 VDC (RH) |
| Approvals | CE |
| RH Accuracy Class | 2% |
| Sensor | Capacitance polymer |
| Compensated Range | -4 to 140 °F (-20 to 60 °C) |
- Lower installation costs when temperature and humidity are combined.
- With 2%, 3%, and 5% accuracy and a wide range of temperature sensors, there is a wide application environment.
- Lower system operating costs thanks to the radiation barrier that shields the sensor from heat radiation.
