Dwyer RMB-50D | Rate-Master Flowmeter | 1.2-10 SCFH (0.6-5 LPM) Air, 5" Scale, No Valve
Dwyer RMB-50D covers 1.2-10 SCFH (0.6-5 LPM) air on a direct-reading 5" (127 mm) Rate-Master scale, supplied without a valve. Intended for general gas and liquid service, this RMB series unit (RMB-50D) mounts on a surface or in a panel.
- Range 1.2-10 SCFH (0.6-5 LPM) air on the 5" (127 mm) scale, no valve fitted
- 3% accuracy and 1/4" female NPT process connections on the RMB-50D
- RMB-50D rated to 100 psi (6.9 bar) and 130°F (54°C) maximum operating conditions
- Wetted parts of the RMB-50D: polycarbonate body, Neoprene/Buna-N O-rings, stainless steel metal parts
- RMB-50D body swaps within its 5" scale size for cleaning or a range change, leaving pipework in place
- Weighs 13 oz (368.5 g); the RMB-50D meets RoHS II (EU Directive 2011/65/EU)
- Specifications
- Features
- Downloads
| Part Number | RMB-50D |
| Brand | Dwyer |
| Accuracy | 3% |
| Weight | 13 oz (368.5 g) |
| Process Connection | 1/4" female NPT |
| Wetted Materials | Polycarbonate body; Neoprene and Buna-N O-rings; SS metal parts; float of SS, black glass, aluminium, K monel or tungsten carbide depending on range |
| Approvals | Meets EU Directive 2011/65/EU (RoHS II) |
| Mounting | Surface or panel |
| Max. Operating Pressure | 100 psi (6.9 bar) |
| Flow Range | 1.2-10 SCFH (0.6-5 LPM) air |
| Scale | 5" (127 mm) |
| Valve | No Valve |
| Max. Operating Temperature | 130 °F (54 °C) |
- Direct reading scales remove the need for difficult conversions.
- Because the stainless steel backbone absorbs pipe torque, installation damage and costs are reduced.
- Long operational life and a sturdy, non-breakable polycarbonate body.
- Precision injection molding around a precisely tapered pin allows for high reproducibility.
- Improved precision of reading because to unique integrated flow guides that control float movement.
- With the ability to read flow instantly from scale graduations on both sides of the indicating tube, you can save time.
