Dwyer TUF-400-BN | Ultrasonic BTU Meter | DN40, 10 m³/h, BACnet

Part Number : TUF-400-BN

The Dwyer TUF-400-BN tenant ultrasonic BTU flowmeter is built for DN40 lines with a 10 m³/h permanent flow rate and BACnet communication, measuring the heating or cooling energy used by a circuit through its built-in energy calculator.

  • G2 threaded meter connection for DN40 pipe, permanent flow 10 m³/h
  • BACnet communication per the listing; serial interface selectable between BACnet MS/TP and Modbus RTU
  • Class 2 energy accuracy (EN1434/CJ128), 1% flow repeatability
  • Unidirectional flow; horizontal or vertical mounting
  • IP65 enclosure, 1 W consumption, pressure drop under 10 kPa
  • Rated to 16 bar for DN15 to DN40; weight 3 kg
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
