Dwyer VFA-4-EC-SS | Visi-Float Acrylic Flowmeter | 1-10 SCFH Air, 2" Scale, 5% FS

Part Number : VFA-4-EC-SS

For flows of 1-10 SCFH in air, Dwyer offers the VFA-4-EC-SS, a Visi-Float acrylic-body flowmeter with a 2" (51 mm) reading scale. The VFA-4-EC-SS belongs to the 2" scale group, which accepts an optional precision metering valve.

  • Vertical mounting
  • RoHS II (2011/65/EU) compliant
  • Rated accuracy of 5% FS
  • 1/8" female NPT process connection
  • Without valve: 150 psig (10 bar) at 100 °F (38 °C) or 100 psig at 150 °F
  • Float in SS, black glass, aluminium or K monel depending on range
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
