Dwyer VFC-123 | Visi-Float Acrylic Flowmeter | 10-100 SCFM Air, 5" Scale, 2% FS
The Dwyer VFC-123 is a Visi-Float flowmeter in the 5" VFC size, scaled 10-100 SCFM air and accurate to 2% of full scale. The VFC-123 has 1" female NPT back connections, with end connections available as an option. The VFC-123 sits in the 5" VFC size of the Visi-Float range.
- 24 to 25 oz (0.68 to 0.71 kg) weight
- Vertical mounting
- RoHS II (2011/65/EU) compliant
- Use with liquids or gases
- Accuracy: 2% of full scale
- Back-mounted 1" female NPT ports, end ports optional
- Specifications
- Features
- Downloads
| Part Number | VFC-123 |
| Brand | Dwyer |
| Type | Visi-Float Flowmeter |
| Accuracy | 2% of full scale |
| Weight | 24 to 25 oz (0.68 to 0.71 kg) |
| Process Connection | 1" female NPT back; end connections optional |
| Wetted Materials | Acrylic body; Buna-N O-ring (fluoroelastomer available); SS metal parts and float; PVC fittings (VFC) |
| Approvals | RoHS II (EU Directive 2011/65/EU) |
| Mounting | Vertical |
| Range | 10-100 SCFM air |
| Scale Length | 5" (127 mm) |
- Solid, transparent acrylic blocks are used for the body's cutting and precise machining, enabling thorough visual examination.
- The float is easier to see on a white background, which improves reading accuracy.
- The material has direct reading scales hot stamped onto it, extending the life of the product and removing the need for laborious conversions.
- A very repeatable tapered bore made by precision machining is possible.
- Minimal installation expenses with options for end or back connections.
