Fluidwell E490P | Explosion proof Multi-Purpose Indicator (pressure version) | Loop Powered, for universal applications, ambient -40°C to +70°C
Part Number : E490P
The E490 is a versatile, loop powered multi-purpose indicator to display the actual process value, range and loop current. Besides the focus on level, temperature and pressure applications, the E490 can also work with other measuring units, like %, mA, RPM and even the possibility to create a custom unit with max. 8 characters. The measuring unit to be displayed is simply selected through an alfa-numerical configuration menu. Typical use: Universal applications when a local loop-powered multi-purpose display is required without monitoring function, linearization or signal re-transmitting.
Key features
- Explosion proof according ATEX, IECEx and CSA C-US.
- Universal loop powered indicator.
- Input signal: Galvanically isolated 4 - 20mA with ultra low voltage drop < 1.5V DC, allowing easy installation in almost any 2-wire, 4–20mA loop.
- Create a custom measuring unit with max. 8 characters.
- Aluminum or high grade stainless steel Ex d enclosure.
- Easy installation with the spacious chamber and plug & play connectors.
- Key information at a glance as the display shows the actual value, measuring unit and loop current and a 10 segments bargraph.
Free Kuwait shipping available
For pricing, please contact our experts.
