Gagemaker LG-6002, 2-point internal lead gage, 0.0005" Resolution ,  ½" – 4" (0 mm – 101.6 mm)Thread Length - generaltechuae

Gagemaker LG-6002 | 2-Point Internal Lead Gage | 0.0005" Resolution, ½" – 4" Thread Length

Part Number : Gagemaker LG-6002

Gagemaker LG-6002 is a 2-point internal lead gage reading to 0.0005", for thread lengths of ½" – 4". The LG-6002 uses a two-point system with a sweeping action to read lead on straight and tapered threads.

  • LG-6002: 0.0005" resolution, 0.100" indicator travel
  • LG-6002 contact point spacing 0.200", minimum bore 1.450"
  • 2 point contact on internal threads, ½" – 4" thread length (LG-6002)
  • Interchangeable contact points on the LG-6002 suit a variety of thread forms (default set included; alternatives on request)
  • Set the LG-6002 to a nominal dimension on a lead setting standard (ANSI/API) first
Availability: in stock
Free Kuwait shipping available
For pricing, please contact our experts.
