HIOKI 3120 | VOLTAGE DETECTOR 3120 Z | Non-Metallic Contact Voltage Detector with LED Light
A pen-shaped, non-contact voltage detector with adjustable sensitivity, red LED and audible alert, rated CAT IV 600V. The Hioki 3120 detects 40V to 600V AC without physical contact and includes built-in LED lighting for dim work areas.
Request a quote in under a minute — call +971 6 5436933.
Part number : 3120
The Hioki 3120 Non-Contact Voltage Detector is designed to quickly identify whether an AC conductor is live without requiring physical contact. Its pen-shaped design makes it convenient for electricians, maintenance technicians and other professionals performing electrical safety checks.
The detector senses AC voltage from 40V to 600V and provides both a red LED indication and an audible alert when voltage is detected. This allows users to quickly confirm the presence of voltage before beginning electrical work.
The Hioki 3120 features an adjustable sensitivity range from 40V to 80V AC. The detector is shipped with the sensitivity set at 80V, while the adjustable range allows users to adapt the detector to different working environments and help reduce false triggers caused by nearby wiring.
A built-in LED light helps illuminate the target area when working in dim panel rooms, ceiling spaces or other areas with limited visibility.
The Hioki 3120 carries a CAT IV 600V safety rating and uses non-contact voltage detection technology designed with electrical worker safety in mind.
This model is part of Hioki's dedicated range of measurement instruments available through GeneralTech Shop. Contact our team if you need help confirming whether the Hioki 3120 is the correct variant for your application.
Ready to order the Hioki 3120? Speak to our team. Call +971 6 5436933.
Key Benefits
- Detects 40V to 600V AC without physical contact
- Red LED and audible alert indicate detected voltage
- Adjustable sensitivity from 40V to 80V AC
- Built-in LED light for improved visibility in dim work areas
- CAT IV 600V safety rating
- Pen-shaped design for convenient handling
Who This Product Is Best For
- Electricians performing electrical safety checks
- Maintenance technicians working with electrical panels
- Technicians working in dim panel rooms or ceiling spaces
- Electrical professionals who need quick non-contact voltage detection
- Users who need to check for live AC voltage before beginning electrical work
How to Use
- Adjust the sensitivity setting according to the working environment if required.
- Hold the pen-shaped detector near the conductor without making physical contact.
- Check the red LED and audible alert when voltage is detected.
- Use the built-in LED light to illuminate the target area when working in dim conditions.
- Follow appropriate electrical safety procedures when checking conductors and equipment.
Frequently Asked Questions
What voltage range does the Hioki 3120 detect?
The Hioki 3120 detects AC voltage from 40V to 600V without physical contact with the conductor.
How does the Hioki 3120 indicate detected voltage?
The detector provides both a red LED indication and an audible alert when voltage is detected.
Can the sensitivity of the Hioki 3120 be adjusted?
Yes. The sensitivity can be adjusted from 40V to 80V AC. The unit is shipped with the sensitivity set at 80V.
What safety rating does the Hioki 3120 carry?
The Hioki 3120 has a CAT IV 600V safety rating.
Does the Hioki 3120 have a built-in light?
Yes. It includes a built-in LED light to improve visibility when working in dim areas.
Where can I check pricing for the Hioki 3120?
Pricing is quote-based. Call +971 6 5436933 for current pricing and availability.
Does GeneralTech Shop deliver the Hioki 3120 across the UAE?
Call +971 6 5436933 and the GeneralTech Shop team can confirm delivery availability and timelines for your emirate.
Is a calibration certificate available for the Hioki 3120?
Calibration and certification availability may depend on the order. Call +971 6 5436933 and the team will confirm the available options.
