HIOKI DT4253 | HVAC Digital Multimeter | 1000 V, K-Type Temp, 4–20 mA
Part Number : DT4253
The HIOKI DT4253 is a DT4200-series multimeter tailored to HVAC and building-controls work, combining electrical measurement with K-type temperature, low-current and 4–20 mA signal checks. It also accepts clamp-on current sensors.
- DC 600.0 mV to 1000 V (±0.3%); AC 6.000 V to 1000 V, 40 Hz to 1 kHz
- DC current 60.00 mA to 60.00 A in 4 ranges
- 600.00 μA range for gas control devices and % display for 4–20 mA loops
- Temperature -40.0 °C to 400.0 °C with a K-type thermocouple
- Capacitance 1.000 nF to 10.00 mF; resistance to 60.00 MΩ
- Data download to a computer; 84 × 174 × 52 mm, 390 g
For pricing, please contact our experts.
