HIOKI LR5001 | Humidity Logger | 2 ch, 60,000 data/ch
This LR5001 listing covers HIOKI's temperature-and-humidity logger, which records both values on two channels at intervals down to one second. A STAT mode captures fluctuations between logging intervals, and data can be read to a PC while recording continues.
Key features
- 60,000 data/ch instantaneous; 15,000 statistical
- -40.0 to 85.0 °C and 0 to 100% RH
- One LR6 (AA) cell, about 20 days at 1 s interval
- Data kept even if the battery dies
- Dual display for on-site readings
- Specifications
- Features
- Downloads
| Part Number | LR5001 |
| Brand | HIOKI |
| Weight | 105 g (3.7 oz) |
| Battery Life | Approx. 3 months (1-minute interval, auto power saving, at 20 °C); approx. 20 days (1-second interval, at 20 °C) |
| Humidity Range | 0 to 100 % RH (at sensor environment) |
| Power Supply | 1 × LR6 (AA) alkaline battery |
| Temperature Range | -40.0 to 85.0 °C (-40 to 185 °F) |
| Storage Capacity | Instantaneous value mode: 60,000 data/ch; Statistical value mode: 15,000 data/ch |
| Dimensions (mm) | 79 × 57 × 28 mm (3.11 × 2.246 × 1.10 in) |
| Channels | Temperature 1 ch, humidity 1 ch |
• Easily mount the light-weight, pocket-sized loggers in tight spaces
• Easy-to-see dual display
• Transfer data to PC even during recording
• Replace batteries while recording (30-second limit) Note: Recording is interrupted during battery replacement if the battery is very weak. After batteries are replaced, recording resumes automatically. Previously recorded data is not lost during battery replacement.
• 7 times the memory capacity than predecessor (Record 60,000 data per channel)
• Record without missing fluctuations in STAT mode
• Measurement data is preserved even after the battery dies
• Worry-free backup preserves recorded data even if a new measurement is started by mistake
