ifm IE9203, Inductive Threaded Barrel Proximity Sensor, M8, 2 mm Detection, PNP/NPN NO, 10 → 55 V dc

Client Protection

Dedicated Support

Client Protection

Dedicated Support

ifm IE9203, Inductive Threaded Barrel Proximity Sensor, M8, 2 mm Detection, PNP/NPN NO, 10 → 55 V dc

Name: ifm IE9203, Inductive Threaded Barrel Proximity Sensor, M8, 2 mm Detection, PNP/NPN NO, 10 → 55 V dc
Brand: ifm
SKU: IE9203
Availability: OutOfStock

Part Number : IE9203

Availability: Sold out

Detailed Description
Specifications
Downloads

The ifm electronic inductive sensor is engineered for precision and reliability in industrial applications, delivering seamless detection capabilities across various environments. Designed with a robust threaded housing, this sensor offers exceptional durability, making it suitable for flush mounting. It operates within a broad temperature range, ensuring functionality even under challenging conditions. The sensor’s versatility is amplified by its PNP/NPN electrical design, providing compatibility with diverse systems. With features like reverse polarity protection and short-circuit safety, this product prioritises user security while enhancing performance. Furthermore, its compact dimensions do not compromise on sensing range, ensuring it meets the needs of modern automation setups.

Particularly short housing
For use where space is restricted
Robust metal housing for use in harsh industrial environments
Very high switching frequency
Two-wire technology

Brand	ifm
Thread Size	M8
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	2 mm
Digital Switching Output Type	PNP/NPN
Output Function	NO
Cable Length	2m
Connection Type	Pre-Cabled
Supply Voltage	10 → 55 V dc
Length	42mm
IP Rating	IP67
Mounting Type	Flush
Shielding	Shielded
Series	IE9
Switching Frequency	1 KHz
Switching Current	100 mA
