ifm IF5762, Inductive Threaded Barrel Proximity Sensor, M12, 4 mm Detection, PNP/NPN NO/NC, 10 → 36 V dc

Name: ifm IF5762, Inductive Threaded Barrel Proximity Sensor, M12, 4 mm Detection, PNP/NPN NO/NC, 10 → 36 V dc
Brand: ifm
SKU: IF5762
Availability: OutOfStock

Part Number : IF5762

Availability: Sold out

Detailed Description
Specifications

The ifm electronic inductive sensor is a revolutionary solution designed for precise detection across a variety of applications. Engineered for robustness, this threaded sensor combines advanced technology with durable materials to offer an impressive performance range. With a sensing distance of up to 4 mm, it is adept at operating within differing conditions, including extreme temperatures from -25 to 80 °C. Featuring a versatile output function, the sensor can be configured for normally open or normally closed operations, providing flexibility to meet diverse industry needs. The sensor's compact design, measuring M12 x 1 with a length of 83 mm, ensures compatibility with standard mounting options, making installation straightforward and efficient while guaranteeing reliable operation under demanding circumstances. Its IP67 protection rating affirms its suitability for challenging environments.

Output function normally open or normally closed programmable
Two-wire technology
Wide operating temperature range
Robust metal housing for use in harsh industrial environments
Very high switching frequency

Brand	ifm
Thread Size	M12
Sensor Technology	Inductive
Body Style	Threaded Barrel
Detection Range	4 mm
Digital Switching Output Type	PNP/NPN
Output Function	NO/NC
Connection Type	M12
Supply Voltage	10 → 36 V dc
IP Rating	IP67
Length	83mm
Mounting Type	Non-Flush
Switching Frequency	1.5 KHz
Shielding	Unshielded
Switching Current	400 mA
Series	IF5
