ifm KD5019, Capacitive Rectangular Proximity Sensor, 60 mm Detection, NPN NO/NC, 10 → 36 V dc

Name: ifm KD5019, Capacitive Rectangular Proximity Sensor, 60 mm Detection, NPN NO/NC, 10 → 36 V dc
Brand: ifm
SKU: KD5019
Availability: OutOfStock

Part Number : KD5019

Availability: Sold out

Detailed Description
Specifications
Downloads

The ifm electronic capacitive sensor offers exceptional reliability and precision for diverse applications. It features a robust rectangular housing with an IP65 rating, ensuring durability in challenging environments. The sensor supports a flexible output function, adjustable sensing range up to 60mm, and advanced protection against reverse polarity and short circuits. Its wide operating temperature range and high performance make it ideal for automation tasks.

Easy setting of the sensing range via potentiometer
High noise immunity
Robust housing for use in harsh industrial environments
Output function normally open or normally closed programmable
Long sensing range of 60 mm

Brand	ifm
Sensor Technology	Capacitive
Detection Range	60 mm
Body Style	Rectangular
Output Function	NO/NC
Digital Switching Output Type	NPN
Connection Type	Screw Terminal
Supply Voltage	10 → 36 V dc
Length	105mm
IP Rating	IP65
Mounting Type	Non-Flush
Series	KD
Shielding	Unshielded
Switching Current	250 mA
Switching Frequency	10 Hz
