ifm KQ6006, Capacitive Rectangular Proximity Sensor, 12 mm Detection, NPN NO/NC, 10 → 30 V dc

Name: ifm KQ6006, Capacitive Rectangular Proximity Sensor, 12 mm Detection, NPN NO/NC, 10 → 30 V dc
Brand: ifm
SKU: KQ6006
Availability: OutOfStock

Part Number : KQ6006

Availability: Sold out

Detailed Description
Specifications
Downloads

The ifm electronic capacitive sensor offers precision and durability for detecting materials, including bulk substances and liquids, with a sensing range of up to 12 mm. It is engineered for extreme conditions, operating reliably across temperatures from -25 to 80 °C and featuring high protection ratings (IP65, IP67, IP 69K). The sensor's integration of IO-Link enables seamless communication and monitoring, while its overload and short-circuit protections ensure long-lasting performance. Its compact, user-friendly design makes it versatile for a range of industrial applications.

Output function normally open or normally closed programmable
Clearly visible indication of the switching status by LED
Easy installation with mounting adapters and cable ties
For position detection or level monitoring
Easy parameter setting via IO-Link

Brand	ifm
Sensor Technology	Capacitive
Body Style	Rectangular
Detection Range	12 mm
Digital Switching Output Type	NPN
Output Function	NO/NC
Connection Type	Pre-Cabled
Cable Length	2m
Supply Voltage	10 → 30 V dc
Length	48mm
IP Rating	IP65, IP67, IP69K
Mounting Type	Non-Flush
Switching Frequency	10 Hz
Switching Current	100 mA
Communication Protocol	IO-LINK
Series	KQ
Shielding	Unshielded
