Mitutoyo 103-129 | Outside Micrometer | 0-25 mm, 0.001 mm
Mitutoyo 103-129 measures length, thickness and depth of parts that fit between anvil and spindle over 0-25 mm, reading to 0.001 mm. The 0-25 mm, 0.001 mm version has a baked-enamel finished frame and carbide measuring faces, with a ratchet stop for constant measuring force.
- Range 0-25 mm, graduation 0.001 mm
- Accuracy ±2 µm on the 0-25 mm, 0.001 mm model
- Carbide measuring faces, baked-enamel frame (103-129)
- Ratchet stop for constant force (0-25 mm, 0.001 mm)
- Specifications
- Features
- Downloads
| Part Number | 103-129 |
| Brand | Mitutoyo |
| Range | 0-25 mm |
| Graduation | 0.001 mm |
| Accuracy | ±2 µm |
| Frame | Baked-enamel finish |
| Measuring Surfaces | Carbide |
| Analogue/Digital | Analogue |
| Unit | Metric |
| Force Control | Ratchet stop |
Baked-enamel-finished frame.
• Equipped with Ratchet Stop for constant measuring force.
• Measuring faces: carbide.
• Setting standard included on models measuring above 25 mm / 1" maximum measuring range
