Mitutoyo 126-126 | Screw Thread Micrometer, Interchangeable Tips | 25-50 mm, 0.01 mm, ±4 µm
Part Number : 126-126
The Mitutoyo 126-126 is an analogue screw thread micrometer for 25-50 mm with 0.01 mm graduation and ±4 µm accuracy. The 126-126 takes optional interchangeable anvils and spindle tips in matched pairs, so one frame can measure metric/unified and Whitworth pitch diameters directly.
- Range 25-50 mm, graduation 0.01 mm on the 126-126
- Accuracy ±4 µm
- Ratchet stop for consistent measuring force
- Spindle lock, Ø6.35 mm spindle, 0.5 mm pitch
- Ø18 mm satin chrome thimble and sleeve; mass 290 g
- 60° metric (unified) setting standard included
