Mitutoyo 126-131 | Screw Thread Micrometer, Interchangeable Tips | 150-175 mm, 0.01 mm, ±6 µm
Part Number : 126-131
Measuring 150-175 mm in 0.01 mm steps to ±6 µm, the Mitutoyo 126-131 reads screw pitch diameter directly with no calculation. For the 126-131, anvils and spindle points are bought separately and fitted as matched pairs for metric/unified or Whitworth threads.
- 150-175 mm range, 0.01 mm graduation
- Rated to ±6 µm
- Ratchet stop gives a repeatable measuring force, 126-131
- Lockable Ø6.35 mm spindle, 0.5 mm pitch on the 126-131
- Satin chrome Ø18 mm thimble, 730 g main unit
- 60° metric (unified) setting standard included for the 126-131
Free Kuwait shipping available
For pricing, please contact our experts.
