Mitutoyo 126-135 | Screw Thread Micrometer, Interchangeable Tips | 250-275 mm, 0.01 mm, ±7 µm
Part Number : 126-135
Measuring 250-275 mm in 0.01 mm steps to ±7 µm, the Mitutoyo 126-135 reads screw pitch diameter directly with no calculation. For the 126-135, anvils and spindle points are bought separately and fitted as matched pairs for metric/unified or Whitworth threads.
- 250-275 mm range, 0.01 mm graduation
- Rated to ±7 µm
- Ratchet stop gives a repeatable measuring force, 126-135
- Lockable Ø6.35 mm spindle, 0.5 mm pitch on the 126-135
- Satin chrome Ø18 mm thimble, 1370 g main unit
- 60° metric (unified) setting standard included for the 126-135
Free Kuwait shipping available
For pricing, please contact our experts.
