Mitutoyo 126-142 | Screw Thread Micrometer | 5-6 in, 0.001 in graduation
Part Number : 126-142
Covering 5-6 in with 0.001 in graduation, the Mitutoyo 126-142 is an analogue screw thread micrometer that reads pitch diameter directly, with no calculation, once a matched pair of optional anvil and spindle tips is fitted. Tips are available for metric/unified and Whitworth threads.
- Measuring range 5-6 in, read on a 0.001 in thimble scale
- Ratchet stop on the 126-142 for an even measuring force
- Spindle lock with a Ø6.35 mm spindle and 0.635 mm spindle pitch
- 60° metric (unified) setting standard supplied, since the 5-6 in range does not start at zero
- Satin-chrome thimble and sleeve, Ø18 mm; main unit 620 g
