Mitutoyo 146-135 | Internal Groove Micrometer | 3-4 in, Rotating Spindle, 0.5 in Flange
Covering 3-4 in, the Mitutoyo 146-135 internal groove micrometer has a 0.5 in flange and rotating spindle for measuring groove width and position in bores. The 146-135 has a two-directional ratchet stop and a 0.001 in graduation.
- Outside range 3-4 in, 0.5 in flange, rotating spindle
- Spindle pitch 0.635 mm, hardened measuring surfaces (3-4 in, rotating, 0.5 in flange)
- Mass 160 g; box and key included (146-135 rotating)
- Specifications
- Features
- Downloads
| Part Number | 146-135 |
| Brand | Mitutoyo |
| Spindle Type | Rotating |
| Flange | 0.5 in |
| Range Outside | 3-4 in |
| Graduation | 0.001 in |
| Spindle Pitch | 0.635 mm |
| Analogue/Digital | Analogue |
| Mass | 160 g |
| Delivered | Box, key |
| Measuring Surfaces | Hardened |
| Scale | Satin chrome thimble and sleeve, Ø18 mm |
his Internal Groove Micrometer is designed to measure the width and location of grooves cut into bore walls.
It offers the following features:
- Two-directional ratchet stop.
- Non-rotating spindle models are also available.
