Mitutoyo 2050A | Lug Back Dial Gauge | 0.01 mm, ISO
Part No. 2050A | Range 20 mm | Graduation 0.01 mm | Lug Back
Product Overview
The Mitutoyo 2050A is an ISO-type Series 2 plunger-type dial gauge with a lug back, 0.01 mm graduation and a 20 mm measuring range. It is designed for long-travel measurement applications including checking heights, steps, runout and machine alignment.
The 2050A follows ISO-type design dimensions, making it important to confirm compatibility with the stands, holders and fixtures used in the inspection setup. Its 20 mm measuring range provides long travel in a single setup, helping reduce the need to repeatedly reposition the gauge during inspection.
The lug-back design provides a dedicated rear mounting point for securing the gauge directly to a suitable bracket or fixture. Its mechanical movement is suited to dependable, day-to-day comparative measurement in workshop and inspection environments.
For applications requiring a flat-back configuration, the Mitutoyo 2050AB provides the corresponding alternative with the same 0.01 mm graduation and 20 mm range.
Key Benefits
-
0.01 mm graduation for clear and practical readings
-
20 mm measuring range for long-travel inspection
-
ISO-type design for inspection setups using compatible ISO-pattern equipment
-
Lug back for direct mounting to suitable brackets and fixtures
-
Plunger-type construction for comparative measurement applications
-
Mechanical movement for routine workshop and inspection use
-
Genuine Mitutoyo part supplied by General Tech Services LLC in Kuwait
Who This Product Is Best For
-
Inspectors measuring heights, steps and runout over a longer stroke
-
Toolrooms and machine shops performing workpiece and machine alignment checks
-
Maintenance teams replacing an existing ISO-type lug-back dial gauge
-
Quality-control teams performing comparative dimensional inspection
-
Buyers standardising inspection equipment around Mitutoyo dial gauges
How to Use It
-
Mount the gauge securely using its lug back or a suitable stem mounting arrangement on a rigid bracket, stand or fixture, keeping the plunger aligned with the surface being measured.
-
Apply a small amount of pre-load to the plunger and rotate the bezel to establish zero against a suitable reference surface or master.
-
Move the workpiece or gauge across the feature being inspected and observe the dial reading to determine the deviation.
-
Retract the plunger carefully after measurement and store the gauge clean, dry and protected.
Frequently Asked Questions
What is the Mitutoyo 2050A dial gauge used for?
The Mitutoyo 2050A is designed for long-travel measurement of heights, steps, runout and machine alignment. Its 0.01 mm graduation and 20 mm range support comparative inspection over a longer measuring stroke.
What are the graduation and measuring range of the 2050A?
The Mitutoyo 2050A has a 0.01 mm graduation and a 20 mm measuring range.
What does ISO-type mean on the Mitutoyo 2050A?
ISO-type refers to the design pattern specified for the gauge. Compatibility with the particular stands, holders and fixtures in an existing setup should be confirmed before installation.
What is the benefit of a lug-back design?
The lug back provides a dedicated mounting point that allows the gauge to be secured directly to a suitable bracket or fixture.
What is the difference between the 2050A and 2050AB?
Both are listed with a 0.01 mm graduation and a 20 mm measuring range. The 2050A uses a lug-back configuration, while the 2050AB uses a flat-back configuration. The appropriate model depends on the mounting arrangement of the inspection setup.
Is the genuine Mitutoyo 2050A available in Kuwait?
General Tech Services LLC supplies genuine Mitutoyo products in Kuwait. For current pricing, lead time and stock availability, call +965 9807 4888.
