Mitutoyo 2802SB-10 | Flat Back Dial Indicator | 0.025 in, 0.0001 in, ANSI/AGD
Part No. 2802SB-10 | Range 0.025 inch | Graduation 0.0001 inch | Flat Back
Product Overview
The Mitutoyo 2802SB-10 is an ANSI/AGD-type Series 2 plunger-type dial gauge with a flat back, 0.0001 inch graduation and a 0.025 inch measuring range. It is designed for high-resolution comparative inspection where very small deviations need to be detected.
Made to American Gage Design dimensions, the 2802SB-10 is suitable for compatible stands, holders and fixtures used in inspection rooms and machine-shop environments. Its 0.0001 inch graduation provides fine resolution over the 0.025 inch measuring range, making it suitable for precision comparative checks, setting gauges and comparing components against a suitable master.
The flat-back design provides a clean, low-profile rear profile for applications where the gauge is mounted by its stem in a magnetic base, comparator stand or custom fixture. Its mechanical movement is suited to routine comparative measurement and day-to-day workshop inspection.
For applications requiring a lug-back configuration, the supplied reference identifies the Mitutoyo 2802A-10 as the corresponding alternative.
Key Benefits
-
0.0001 inch graduation for fine, high-resolution readings
-
0.025 inch measuring range for precision comparative inspection
-
ANSI/AGD-type Series 2 design for compatibility with suitable inspection setups
-
Flat back for stem mounting in stands, magnetic bases and fixtures
-
Plunger-type construction for comparative measurement applications
-
Mechanical movement for routine workshop and inspection use
-
Genuine Mitutoyo part supplied by General Tech Services LLC in Kuwait
Who This Product Is Best For
-
Quality-control inspectors performing high-resolution comparative measurement
-
Toolrooms and machine shops checking precision components and workpieces
-
Inspection teams setting gauges or comparing components against a master
-
Maintenance teams replacing an existing ANSI/AGD flat-back dial gauge
-
Buyers standardising precision inspection equipment around Mitutoyo products
How to Use It
-
Mount the gauge securely by its stem in a suitable rigid stand, magnetic base or fixture, keeping the plunger aligned with the surface being measured.
-
Apply a small amount of pre-load to the plunger and rotate the bezel to establish zero against a suitable reference surface or master.
-
Move the workpiece or gauge across the feature being inspected and observe the dial reading to determine the deviation.
-
Retract the plunger carefully after use and store the gauge clean, dry and protected.
Frequently Asked Questions
What is the Mitutoyo 2802SB-10 dial gauge used for?
The Mitutoyo 2802SB-10 is designed for high-resolution comparative inspection where very small deviations need to be measured. Its 0.0001 inch graduation and 0.025 inch range support fine-tolerance inspection applications.
What are the graduation and measuring range of the 2802SB-10?
The Mitutoyo 2802SB-10 has a 0.0001 inch graduation and a 0.025 inch measuring range.
What does ANSI/AGD mean on the Mitutoyo 2802SB-10?
ANSI/AGD refers to the American Gage Design standard for dial indicators. The standardized design dimensions are intended for compatibility with suitable stands, holders and accessories.
What is the benefit of a flat-back design?
The flat back provides a clean, compact rear profile for applications where the gauge is mounted by its stem in a stand, magnetic base or custom fixture.
What is the difference between the 2802SB-10 and 2802A-10?
Both are listed with a 0.0001 inch graduation and a 0.025 inch measuring range. The 2802SB-10 uses a flat-back configuration, while the 2802A-10 uses a lug-back configuration. The appropriate model depends on the mounting arrangement of the inspection setup.
Is the genuine Mitutoyo 2802SB-10 available in Kuwait?
General Tech Services LLC supplies genuine Mitutoyo products in Kuwait. For current pricing, lead time and stock availability, call +965 9807 4888.
Request Pricing and Availability
For the genuine Mitutoyo 2802SB-10 dial gauge in Kuwait, contact General Tech Services LLC for current pricing, stock availability and lead-time information.
Call +965 9807 4888 for pricing and stock availability.
