Mitutoyo 2937S-10 | Dial Indicator | 0.02 in Range, 0.0001 in Graduation
The Mitutoyo 2937S-10 is a dial indicator with a 0.02 in measuring range and 0.0001 in graduation. Mitutoyo lists the 2937S-10 for quality control and inspection.
- 0-4-0 dial graduations
- Rated accuracy ±0.0001 in
- Measuring force of 2 N or less
- 0.0001 in per division
- Range 0.02 in
- Specifications
- Features
- Downloads
| Part Number | 2937S-10 |
| Brand | Mitutoyo |
| Range | 0.02 in |
| Graduation | 0.0001 in |
| Accuracy | ±0.0001 in |
| Dial Reading | 0-4-0 |
| Measuring Force | 2 N or less |
- Improved immunity to shock from abrupt spindle retraction brought on by high impact is provided by a special shock-proof mechanism.
- For durability and scratch resistance, the crystal is hard coated.
- It weighs around 40% less than a traditional dial indication.
- enhanced resistance to dust and water, two common pollutants found on shop floors.
- When clamping along the stem, spindle movement won't be impeded or jammed since the spindle bushing is offset from the stem.
- For quick and simple tolerance judgment (GO/±NG), a pair of limit hands are provided.
