Mitutoyo 314-362-30 | 3-Flute V-Anvil Digital Micrometer | 0.4-1 in
This Mitutoyo 314-362-30 Digimatic micrometer has a 60° V-anvil for 3-flute reamers, taps and end mills in the 0.4-1 in range.
- Range 0.4-1 in for 3-flute tools
- Digital step 0.00005 in; mass 410 g
- Anvil prism set at 60°; 6.35 mm spindle, lockable, 0.75 mm pitch
- Data output provided, with ZERO/ABS; up to approx. 2.4-year battery life
- Checks OD of 3-flute reamers, taps and end mills
- Delivered with box, key, battery and setting standard
- Specifications
- Features
- Downloads
| Part Number | 314-362-30 |
| Brand | Mitutoyo |
| Range | 0.4-1 in |
| Flutes | 3 |
| Prism Angle | 60° |
| Digital Step | 0.00005 in |
| Flatness | 0.000012 in |
| Units | Inch/Metric |
| Spindle | 6.35 mm, with lock, 0.75 mm pitch |
| Data Output | Yes |
| Battery Life | Approx. 2.4 years |
| Mass | 410 g |
| Supplied With | Box, setting standard, key, 1 battery |
This Digimatic V-Anvil Micrometer helps you measure cutting tools and taps.
It offers the following benefits:
- It measures the outside diameter of cutting tools (such as taps, reamers, end mills) which have three or five flutes.
- V-anvils with a centreline groove are available for measuring the pitch diameter of taps by the single-wire method.
